Spiral fracture of the distal third of the tibia along with posterior malleolus fracture is a unique type of complex fracture with a high incidence that is seen regularly in clinical practice. Because a posterior malleolus fracture is easily concealed, the displacement is often not obvious. Conventional plain film radiography does not make it easy to identify, so the clinical misdiagnosis rate is high. At present, there is no standard treatment for this type of posterior ankle fracture. From January 2010 to June 2016, 61 cases of spiral fracture of the distal third of the tibia along with ankle fracture of the posterior malleolus were repaired using medial anatomic plate fixation at our hospital. Three cannulated screws were used in the treatment of 27 cases, and the remaining 34 cases were treated with an L-type steel plate; a comparison was made between the two treatment methods to determine which was most effective.

General information

Out of the 61 cases with this type of injury, 34 were treated with three cannulated screws. There were 23 males and 11 females who ranged in age from 27–71 years old (average: 38.4 years). Three of these fractures were open; 18 cases also presented with a proximal fibula fracture, while a distal fibula fracture was diagnosed in 7 cases. The causes of these injuries were traffic accidents in 22 patients, sprains in 7, and other causes in the remaining 5. In the treatment group, 27 cases were repaired using a steel plate. Nineteen of these were male, and eight were female. This group ranged in age from 26–68 years, with an average age of 39.2 years. Only one patient in this group had an open fracture. However, 13 presented with a proximal fibular fracture, and 8 also suffered a distal fibular fracture. The causes of these injuries were traffic accidents in 17 patients, sprains in 6, and other causes in the remaining 4. The size of the fractured fragment in these two groups ranged from 25–50% of the total size of the posterior malleolus.

Operative methods

All patients received epidural anesthesia and a lower limb tourniquet. All cases were treated with steel plate fixation of the tibial fractures. In the treatment group, a hollow screw with a length of about 10 cm was wound along the midline between the lateral malleolus and the Achilles tendon’s trailing edge. When distal fibula fractures were present, fibula fixation was carried out using the same surgical wound. During subcutaneous tissue layer separation, close attention was paid to the protection of the Achilles tendon and the lateral sural nerve. The deep fascia was incised to expose the peroneal tendon. After lateral retraction, the tendon was exposed below the hallux longus and then retracted medially to reveal the distal tibia and posterior malleolus fracture block Volkmann. If a conversion to an open reduction and temporary fixation were required, an assessment of the reduction was carried out using needle-guided, intraoperative C arm fluoroscopy to determine the block level of the articular surface. When the surgeon was satisfied with the hollow drill-guided pinhole, the guide wire insertion proceeded for the three 4.0-mm hollow screws. A small fracture block often makes it difficult to insert three cannulated screws to eliminate the test. In the cannulated screw fixation group, the fracture block was fixed under direct visualization and was temporarily fixed using Kirschner wire. The level of reduction of the articular surface was evaluated intraoperatively using C arm fluoroscopy.

Postoperative treatment

Two groups of patients were treated without external fixation (such as plaster) and with antibiotics to prevent infection within 24 hours postoperatively. On the third day following surgery, patients were allowed to participate in passive and active functional ankle exercises. They were not allowed to bear any weight at all on the ankle until 4 weeks after the operation. At 8 weeks following surgery, participants could take part in limited weight bearing with protection. They were only cleared for full weight bearing on the ankle 12 weeks postoperatively if an imaging examination showed that the fracture had healed sufficiently.

Efficacy evaluation criteria

The function of the ankle joint was assessed according to the Baird-Jackson scoring system ^[1]. The results from the x-ray (25 points), stability (15 points), walking ability (15 points), pain (15 points), activity (10 points), ability to work (10 points), and running capacity (10 points) scores were used to evaluate ankle function to generate a total out of a highest possible score of 100 points. A total score in the 96–100 range was classified as excellent, which meant that the ankle joint had recovered completely without pain and patients had no activity restrictions. An overall score from 91–95 was classified as good, where the ankle’s range of motion for ankle flexion and extension was normal or limited by no more than 15 degrees. These patients reported being tired or having occasional pain with activity but had no activity or work restrictions. A fair total score ranged from 91–80; at this score, patients experienced ankle joint movement limitations of less than 30 degrees and occasional pain. They were allowed to engage in light physical labor. All scores <80 points were classified as poor because patients often experienced pain and had limited joint motion greater than 30 degrees.

Statistical methods

Data were statistically analyzed using the Statistical Package for the Social Sciences (SPSS), version 12.0, statistical software for Windows. Measurement data were reported as the mean and standard deviation (x±S). If the data were normally distributed, group-designed t tests were used. Count data were analyzed using χ2 test, and a P-value < 0.05 indicated statistical significance.

All 61 cases were followed up for 6–36 months (mean: 20.8 months). The infection rate of the cannulated screw group (0.03%) was slightly lower than that of the steel plate group (0.04%), but there was no significant difference in the infection rate between the two groups (χ2 =1.31, P=0.13 >0.05). Both groups of fractures healed well with no cases experiencing a delayed union or nonunion. The average healing time was 7.3 weeks in the hollow nail group and 7.5 weeks in the steel plate group. There was no significant difference in the healing time between the two groups (t=1.25, P=0.09 >0.05). No significant reduction of ankle fracture was found during follow-up. Ankle joint function was assessed at the time of the last follow-up visit using the Baird-Jackson scoring system. The cannulated screw group had 18 cases with excellent function, 10 with good function, 5 with fair function, and 1 with poor function. The rate of patients who reported good function or better was 82.4%. Ankle function in the steel plate group was excellent in 14 cases, good in 9, fair in 3, and poor in 1 case, with 85.2% reporting good or excellent function. There was no significant difference between these two groups in terms of their Baird-Jackson score (χ2 =1.53, P=0.21 >0.05). In the plate group, one case of postoperative vertical toe deformity appeared with flexor pollicis longus muscle spasms. The condition had improved after plate removal and was no longer obvious.

An overview of spiral fracture of the lower third of the tibia and posterior malleolus fracturen

In routine clinical practice, spiral fractures of the lower third of the tibia and ankle fractures are very common, but spiral fracture of the lower third of the tibia combined with an ankle fracture are not easy to identify using conventional plain x-ray film. Undisplaced fractures, which are often clinically misdiagnosed, are reported in spiral fractures of the distal third of the tibia with posterior malleolar fracture Department of Radiology, diagnostic rate is 67.9% leakage, physicians clinical Department of orthopedics the misdiagnosis rate of 53.6% ^[2]. Therefore, all patients with a spiral fracture of the distal third of the tibia should undergo computed tomography (CT) or magnetic resonance imaging (MRI) of the ankle joint, as the incidence of ankle fracture in these patients is about 81.7% ^[3]. The report of the study on the fracture of the tibia and the fracture of the posterior malleolus of the tibia in the spiral fracture of the tibia 9.7% ^[2]. Stuermer et al.^[4] reported that 3.7% of tibial fractures were also combined with ankle fractures. Kukkonen et al.^[5] found that approximately 83.3% of tibial shaft fractures and posterior malleolus fractures were associated with fractures of the tibia. In the present study, the incidence of spiral fracture of the distal third of the tibia and concurrent ankle fracture was about 76.1% after CT or MRI examination.

At present, there is no definitive treatment for this type of fracture. In posterior malleolus fractures involving less than 25% of the articular surface of the ankle, conservative treatment is typically effective without requiring internal fixation.^[6,7] The study found that after ankle fracture at the attachment point of the posterior tibiofibular ligament, posterior fixation of the ankle fracture can restore syndesmosis stability and reduce the occurrence of ankle joint complications. Some scholars believe that ^[8] in posterior malleolus fractures involving more than 25% of the articular surface of the ankle, there is no clinical difference in conservative and surgical treatment. Another study ^[9] reported that when the posterior malleolus fracture block makes up at least 25% of the ankle joint surface or is combined with subluxation of the talus and manual reduction failure, treatment should be carried out using open reduction surgery. However, in the clinic, the amount of articular surface area involved in the fracture is not the only indication for surgery. The type of fracture and degree of displacement as well as the lower tibiofibular joint stability are also considerations; and surgical operation is possible after ankle fracture displacement caused by it is also the clinical indications for surgery ^[3,10]. Fractures of the lower third of the tibia and of the posterior malleolus are different from a fracture of the posterior ankle. The present study found that 88% of patients had no obvious displacement. Therefore, clinical treatment of this condition should also have a special treatment plan.

A comparison of open reduction and internal fixation using three cannulated screws in the treatment of posterior malleolus fractures with an L-type plate

The purpose of this study was to reduce the incidence of postoperative ankle fracture displacement during functional exercise in patients with tibial fractures and also to compare the outcomes of the treatment of posterior ankle fractures in all patients whose fractured fragment of the posterior malleolus ranged from 25–50% of the articular surface.

Much research has been conducted on the clinical effects of posterior malleolus fractures. Reports on the condition of the ankle fracture block following plate fixation have been increasing in recent years. It has been reported ^[11] that the strength of plate fixation in a posterior malleolus fracture block is greater than that of hollow screws. Therefore, patients who begin early postoperative passive and active functional ankle exercises do not have to worry about the fracture block shifting and affecting their recovery. The author anticipated that L-type plate fixation after ankle fracture block would have the following advantages: ① for comminuted fractures, the block has a good fixation effect; ② it improves the stability of the fixation; and ③ early functional exercise can promote rehabilitation and fracture healing. Clinical work has revealed that hollow screws have a stronger force on cortical and cancellous bone, but their holding force in a large ankle fragment is poor, especially in patients with osteoporosis. When posterior malleolar fractures are comminuted fractures, hollow screws often became loose, leading to easily induced late ankle joint separation. Therefore, comminuted posterior malleolus fractures that are large and occur in patients with osteoporosis should be repaired with plate fixation.

The treatment selection of either an L-type plate or three hollow screws in clinical practice

At present, there is no standard treatment the internal fixation of ankles fractured in two places. It has been suggested that the treatment of posterior ^[12] fractures with cannulated screws can reduce surgical trauma, prevent damage to the blood supply of the posterior malleolus, and facilitate faster fracture healing and therefore an early return to functional exercise. At the same time, research shows ^[13] that while screw fixation is more suitable for bone fractures, a large fracture block requires plate fixation after fracture of the ankle; the effect of plate fixation is superior to that of single screw fixation. Experimental ^[14] studies have found good stability in the posterior facet of the ankle joint when a fracture of 25% of the articular surface was repaired with screw fixation, but it was also just as effective to use plate fixation at the 25% threshold. Dan Jin ^[15] concluded that compared to screws, a plate is better at preventing an upward shift of the fracture block. Erdem et al. ^[16] compared steel plate and screw fixation and reported that both a steel plate and screws can be firmly fixed to the fracture block, so the two groups were not statistically different. Connor et al. [17] found that the plate fixation group had better results than the screw fixation group, but there was no difference between the two groups regarding ankle function; however, the incidence of postoperative traumatic arthritis in the screw fixation group was lower than that in the steel plate fixation group.

There are many confounding factors in these two groups. Our biomechanical study of the articular surface of posterior malleolar fractures that made up 15% of the articular surface found that cannulated screw fixation and triangular L-type plate fixation were effective with no significant difference. When the size of the fragment was between 25–50% of the articular surface, cannulated screw fixation was biomechanically superior to L-type plate fixation even though triangle fixation can provide good stability. When determining the method of internal fixation of a posterior malleolus fracture, it is generally accepted that both screw and plate fixation have their own advantages and disadvantages, but the clinical effect of either is quite good. Screw fixation is minimally invasive and can achieve an effective fixation effect; however, from a biomechanical point of view, steel plate fixation has the advantage and is therefore more conducive to early functional exercise. In this group of cases, there was no significant difference in the clinical efficacy of the two types of internal fixation. Both were effective and feasible, reduced the incidence of surgical re-injury, had a high healing rate, and promoted a fast recovery. For stable fractures of the posterior malleolus, we suggest screw fixation to reduce tissue trauma. However, plate fixation is recommended for comminuted ankle fractures of the posterior malleolus with a size greater than a third of the bone, if the articular surface of the posterior malleolus fracture line is relatively long, or if the patient has osteoporosis to obtain more firm fixation so that patients may begin functional exercise as soon as possible postoperatively.

Fund program: This study is supported by the Shanghai science and Technology Commission (14411972600) and the Shanghai Municipal Health Bureau (2013-319).
